u-bolt

u-bolt

KIA

model : RHINO U-BOLT (F)

  • no.

  • 24-478
    24-479
    24-480-1
    24-480
    24-480-2

  • DIMENSIONS

  • Φ15×76×4.5"
    Φ15×76×7"
    Φ15×76×8"
    Φ15×76×9"
    Φ15×76×10"

  • REMARK

  • OK85034181

u-bolt

KIA

model : RHINO U-BOLT (F) SPECIAL

  • no.

  • 24-479-1

  • DIMENSIONS

  • Φ15×76×7"

  • REMARK

u-bolt

KIA

model :RHINO U-BOLT (R)

  • no.

  • 24-481
    24-482
    24-483

  • DIMENSIONS

  • Φ18×74×15"
    Φ18×74×16"
    Φ18×74×17"

  • REMARK

  • OK85028161A

u-bolt

KIA

model : RHINO U-BOLT (R) SPECIAL

  • no.

  • 24-481-1
    24-482-1
    24-483-1

  • DIMENSIONS

  • Φ18×74×15"
    Φ18×74×16"
    Φ18×74×17"

  • REMARK

u-bolt

KIA

model : RHINO DECK U-BOLT

  • no.

  • 24-484
    24-485
    24-486
    24-487
    24-488
    24-489
    24-490

  • DIMENSIONS

  • Φ15×88×11"
    Φ15×88×12"
    Φ15×88×13"
    Φ15×88×14"
    Φ15×88×15"
    Φ15×88×16"
    Φ15×88×17"

  • REMARK

u-bolt

KIA

model : TRADE U-BOLT (F)

  • no.

  • 2-036-10

  • DIMENSIONS

  • Φ15×72×4.5"

  • REMARK

  • 0W02334181B

u-bolt

KIA

model : TRADE U-BOLT (R)

  • no.

  • 2-036-1
    2-037-1

  • DIMENSIONS

  • Φ18×74×12"
    Φ18×74×13"

  • REMARK

  • JUMBO TITAN (R)

u-bolt

KIA

model :BOXER U-BOLT (F)

  • no.

  • 24-491

  • DIMENSIONS

  • Φ15×72×6"

  • REMARK

  • HYUNDAI 5T (F)

u-bolt

KIA

model : BOXER U-BOLT (F) SPECIAL

  • no.

  • 24-491-1

  • DIMENSIONS

  • Φ15×72×6"

  • REMARK

u-bolt

KIA

model : BOXER U-BOLT (R)

  • no.

  • 24-492
    24-493

  • DIMENSIONS

  • Φ18×74×14"
    Φ18×74×15"

  • REMARK

u-bolt

KIA

model : BOXER U-BOLT (R) SPECIAL

  • no.

  • 24-492-1
    24-493-1

  • DIMENSIONS

  • Φ18×74×14"
    Φ18×74×15

  • REMARK

u-bolt

KIA

model : BOXER DECK U-BOLT

  • no.

  • 24-495
    24-494
    24-495-1
    24-495-2
    24-495-3

  • DIMENSIONS

  • 12"
    13"
    14"
    15"
    16"

  • REMARK

u-bolt

KIA

model : TITAN U-BOLT (F)

  • no.

  • 24-496

  • DIMENSIONS

  • Φ15×72×4.5"

  • REMARK

u-bolt

KIA

model :TITAN U-BOLT (R)

  • no.

  • 24-497

  • DIMENSIONS

  • Φ18×74×12"

  • REMARK

u-bolt

KIA

model : TITAN DECK U-BOLT

  • no.

  • 24-499
    24-500
    24-501
    24-502
    24-503

  • DIMENSIONS

  • Φ15×75×11"
    Φ15×75×12"
    Φ15×75×13"
    Φ15×75×14"
    Φ15×75×15"

  • REMARK

u-bolt

KIA

model : JUMBO TITAN U-BOLT (R)

  • no.

  • 24-504

  • DIMENSIONS

  • Φ18×74×12"

  • REMARK

  • TRADE (R)

u-bolt

KIA

model : BESTA U-BOLT (R)

  • no.

  • 25-511
    25-511-1

  • DIMENSIONS

  • Φ18×74×7.5"
    Φ18×74×8.5"

  • REMARK

  • SAEHAN, 8T

u-bolt

KIA

model : BONGO U-BOLT (R)

  • no.

  • 25-513
    25-513-4
    25-513-1
    25-513-2

  • DIMENSIONS

  • Φ11×78×7.5"
    Φ11×78×8"
    Φ11×78×8.5"
    Φ11×78×9.5"

  • REMARK

  • 190mm
    200mm
    220mm
    240mm

u-bolt

KIA

model : BONGO3 U-BOLT (R)

  • no.

  • 25-514-1
    25-514-3

  • DIMENSIONS

  • Φ13×78×190㎜
    Φ13×78×210㎜

  • REMARK

  • 55225-4E110
    55225-4E110A

u-bolt

KIA

model : CERES U-BOLT (F)

  • no.

  • 24-508
    24-508-1

  • DIMENSIONS

  • LARGE
    SMALL

  • REMARK

u-bolt

KIA

model : CERES U-BOLT (R)

  • no.

  • 24-508-2

  • DIMENSIONS

  • REMARK

u-bolt

KIA

model : COSMOS U-BOLT (F)

  • no.

  • 31-627

  • DIMENSIONS

  • 31-627 Φ16×73×8"

  • REMARK

  • NOVUS (F)

u-bolt

KIA

model : COSMOS U-BOLT (R)

  • no.

  • 31-627-1
    31-627-2

  • DIMENSIONS

  • Φ22×82×13"
    Φ22×82×14"

  • REMARK
